Compliance Standard : Astm D566
Application : Determination of drop point of Lubricating greases
Product Desciption :
The Instrument is used to determine the temperature at which Lubricating grease passes from semi-solid state to liquid state under controlled heating conditions upto 250°C temp. The apparatus consists of a precision heating unit, transparent oil bath, standardized grease cup assembly, thermometer/probe holder, and temperature measurement system for accurate and repeatable results.
Technical Specifications
| Test method | Astm D566 |
| Temp Range | Ambient upto 250°C |
| Temp. Accuracy | +/- 1°C |
| Heating Control | Energy Regulator |
| Construction | Mild Steel body powder coated |
| Bath Medium | Silicon oil as heating medium |
| Power Supply | 230V Ac, Single phase, 50Hz F |
Apparatus is supplied with the following items :
Optional Accessories :
Dimensions and weight (Approx)
| Overall Length | 650-700mm |
| Base width and Depth | 300 mm |
| Heating Unit Height | 230-250mm |
| Net Weight | 12-15 Kgs |
| Gross weight | 18-20 Kgs |
Applications : Lubricating grease, Quality control, Petroleum and lubricant testing Laboratories, Research and development Laboratories.
